Author(s):
Suraj Wasudeo Nagre
Department of CVTS, Grant Medical College, Mumbai, India
Received: 16 August, 2016; Accepted: 29 August, 2016; Published: 30 August, 2016
Dr Suraj Wasudeo Nagre, MBBS, MS, M.Ch, CVTS, DNB, CVTS, Associate Professor, Department of CVTS, Grant Medical College, 31, Trimurti Building, J J Hospital compound, Byculla, Mumbai, India, Mobile no -09967795303; E-mail:
Nagre SW (2016) Hurdles for Starting Ministernotomy Aortic Valve Replacement Program. J Cardiovasc Med Cardiol 3(1): 035-037. DOI: 10.17352/2455-2976.000029
© 2016 Nagre SW. This is an open-access article distributed under the terms of the Creative Commons Attribution License, which permits unrestricted use, distribution, and reproduction in any medium, provided the original author and source are credited.
Aortic valve; Ministernotomy; CPB (cardiopulmonary bypass); VR (aortic valve replacement)
Research article regarding hurdles for starting ministernotomy Aortic valve replacement program in Grant Medical College, Mumbai and techniques to overcome them. Here we studied twenty patients of aortic valve replacement surgery out of which ten are operated by ministernotomy and ten by full sternotomy in our institution, from May 2013 to May 2016.Middle age patients are selected out of which seven had regurgitant and three had stenotic lesion of aortic valve. Our observations are sternotomy time was more in initial cases but it decreased with experience. We faced difficulties in deairing heart and giving shock with routine internal shock paddles. It required special sterile external shock paddles. We required conversion to full sternotomy in two patients because heart continued to fibrillate even giving shock with paediatric internal shock paddles. CPB time, cross clamp time, CCU stay was same as compared to full sternotomy AVR patients. Cosmetically incision was better. Even with early difficulties and hurdles we continued our efforts to improve and succeeded in it. Ministernotomy AVR will always maintain its place in between full sternotomy AVR and minithoracotomy AVR.
Introduction
In this era of percutaneous interventions and minimal invasive surgery, ministernotomy aortic valve replacement is good option to start minimal invasive cardiac surgery in any institute. Aortic valve replacement seems more feasible through ministernotomy as aorta is anterior structure and cannulation required can be done through exposed aorta and right atrium [1]. Most importantly it can be done with same intruments that are used in conventional full sternotomy aortic valve replacement. Patients with same criteria (Table 1), are selected and divided into two groups. In Group one 10 cases undergone ministernotomy AVR anvd in Group two 10 cases undergone conventional full sternotomy AVR .Observations in both groups are compared.
Patients and Methods
Twenty patients of aortic valve replacement surgery - ten by ministernotomy and ten by full sternotomy studied at our institution Grant Medical College, Mumbai from May 2013 to May 2016.
In both groups, techniques used for heparinisation, cannulation (Figure 1), going on bypass, aortic valve excision (Figure 2a,b), mechanical valve used ,suturing technique (pledgetted ethibond with pledget on left ventricle side), all are same. Intraopt and postopt observations in both groups are compared.
-
Figure 1:
All canulations as routine. Arterial aortic cannula, venous dual stage cannula in right atrial appendage and cardioplegia cannula in ascending aorta.
-
Figure 2:
a). Adequate aortic valve exposure. b). No difficulty in sizing the aortic annulus.
Intraopt observation
Postopt observation
➢ Single pericardial drain was placed which was removed after 48 hours and incision size was 5 cm only (Figure 3a,b).
➢ Less pain [pain score reduced to 6].
➢ Early mobilisation and discharge from hospital.
➢ No reexploration.
➢ Reoperation required in one patient due to significant paravalvular leak cause may be defective surgical technique.
➢ No Mortality.
-
Figure 3:
a). Single pericardial drain b) 5 cm incision site.
Comparision [2,3]
➢ Sternotomy time was more in initial cases of ministernotomy group but it decreased with experience.
➢ CPB time, cross clamp time, CCU stay was same as compared to full sternotomy AVR patients.
➢ Ministernotomy incision was cosmatically superior and without any complications as compared to full sternotomy incision.
➢ Pain was less in ministernotomy group.
Discussion
Starting ministernotomy aortic valve replacement program was challenging. What Hurdles we faced and techniques to overcome them are discussed here
Sternotomy
Initial cases it was slightly difficult and time consuming to do ministernotomy but with time and experience duration became less. For easy access to right atrial appendage and for insertion of vent through LA-RSPV junction, we preferred right side ministernotomy that is J shaped rather than L shaped. It was preferable to keep the saw side by in sterile tray after ministernotomy so that in emergency if full sternotomy required can be done easily [4].
First the suprasternal notch and xiphoid are marked and then 2 cm below suprasternal notch manubriosternal joint was marked .5cm incision was taken starting from manubriosternal joint (Figure 4) towards xiphoid.
-
Figure 4:
Incision and sternotomy.
Pursestring and suturing
It was preferable to take pursestring by open hand grip method of holding the needle holder (Figure 5). It allows use of minimum space without any difficulty.
-
Figure 5:
Open hand grip technique for suturing.
Deairing
Difficulty in deairing because of limited exposure and enlarged left ventricle. It overcome by giving hot shot and deairing through left atrium roof and appendage by direct needle aspiration. It can be overcome by use of carbondioxide insufflation if available. Transesophageal echocardiography was useful for complete deairing.
Massaging
Proper cardiac massage was difficult due to limited exposure and enlarged left ventricle. As a result heart tends to fill with blood and become distended causing subendocardial ischemia hampering the myocardial protection.
Shock delievery
Due to difficulty in deairing and massaging, heart tend to fibrillate and even by using peadiatric shock paddles it was not possible to reach left ventricle through ministernotomy route. Two of our first patients required conversion to full sternotomy for same. Use of disposable external shock paddles (Figure 6) become important prerequisite for ministernotomy surgeries.
-
Figure 6:
Disposable external shock paddles on back.
Advantages of ministernotomy aortic valve replacement
Without increase in operative time, ministernotomy provides adequate exposure, good cosmesis and less pain. Main hurdle encountered was while delivering shock when heart was fibrillating and overcame by using disposable external shock paddles. It preserves respiratory mechanics. Cost savings as no new equipment was required. Early mobilization and reduced hospital stay. Ease of conversion to full sternotomy. Redosternotomy becomes easier [5,6].
Postopt 2 D Echo of first ministernotomy AVR patient showed significant paravalvular leak due to surgical technique problem requiring reoperation within 20 days.
Disadvantages of ministernotomy aortic valve replacement
Inability to visualize whole heart. Difficulty in deairing the heart. Difficulty in applying the epicardial pacing wires so it is better to apply when patient is on CPB. Limited control in case of heamorrhge. Steep learning curve.
Conclusion
Disposable external shock paddles and transesophageal echocardiography is must. Ministernotomy AVR though technically challenging but with increased surgical experience, it offer results comparable to the conventional full sternotomy AVR. Ministernotomy AVR will always maintain its place in between full sternotomy AVR and minithoracotomy AVR. Even with early difficulties and operative hurdles we continued our efforts to improve and succeeded in it.
Limitation of our study
➢ Number of cases studied are small.
➢ Patients above forty years of age are not in study.
➢ Degenerative and calcific aorta are get excluded from study.
Ethical Approval
All procedures performed in studies involving human participants were in accordance with the ethical standards of the institutional and/or national research committee and with the 1964 Helsinki declaration and its later amendments or comparable ethical standards.
-
-
- Benetti FJ, Mariani MA, Rizzardi JL, Benetti I (1997) Minimally invasive aortic valve replacement. J Thorac Cardiovasc Surg 113: 806-807 .
- Liu J, Sidiropoulos A, Konertz W (1999) Minimally invasive aortic valve replacement (AVR) compared to standard AVR. Eur J Cardiothorac Surg 16: S80-83 .
- Detter C, Deuse T, Boehm DH, Reichenspurner H, Reichart B (2002) Midterm results and quality of life after minimally invasive vs. conventional aortic valve replacement. Thorac Cardiovasc Surg 50: 337-341 .
- Svensson LG, D’Agostino RS (1998) “J” incision minimal-access valve operations. Ann Thorac Surg 66: 1110-1112.
- Tabata M, Khalpey Z, Shekar PS, Cohn LH (2008) Reoperative minimal access aortic valve surgery: minimal mediastinal dissection and minimal injury risk. J Thorac Cardiovasc Surg 136: 1564-1568.
- Byrne JG, Aranki SF, Couper GS, et al. (1999) Reoperative aortic valve replacement: partial upper hemisternotomy versus conventional full sternotomy. J Thorac Cardiovasc Surg 118: 991-997 .
-
-
-
Table 1:
Patient Selection Criteria In Group 1 and Group 2.
